6007 Ecotimer
-
The HRT 6007 is an electronic floor-temperature controller without timer function.
Applications include electric heaters (direct heating systems, space heaters, temperature systems, heating pads, etc.) and floor warm water heating systems (the latter via thermal actuators, normally closed).
The floor-temperature controller HRT 6007 enables set the target floor temperature to with the setting wheel. The heating operation is indicated by LED. The red LED lights up as long as the controller has switched on the heating.
Delivered the HRT 6007 – floor-temperature controller without timer function with HRT frame (50x50 standard). This makes the controller integrated into most programs leading switch manufacturers. On request delivery with Busch-Jaeger-frame, Reflex SI program.
The temperature control device is delivered with a floor sensor.
-
Weight 70 g Dimensions 36 × 80 × 80 cm temperature range 10 – 60 °C, 10 – 40 °C
display type without display
mains voltage 230 V ~ ± 10%, 50 Hz
switching current (max.) approximately 12 (4) A
switching power 2,7 kW
switching temperature difference 0,7 K
temperature sensor NTC acc. to DIN 44574
perm. ambient temperature -10 – +40 °C
connection cables 2,5 mm²
degree of protection IP 30
energy class IV
energy efficiency 2,0%
functions continuous operation, manual mode
Relay contact opens at overtemperature
LED display with the heating switched on
control floor temperature control
operating element on / off switch, setting wheel
floor sensor ntc 02 kOhm / HRT sensor, floor sensor hrt included
temperature sensor cable 4 m long, max. diameter 8 mm
weight of the floor sensor 140 g
color creme white, pure white
compatibility 50 x 50 mm, with intermediate frame
-
-
—
-
—
-
—
-
—
-
—
-
